A proven and reliable control system, incorporating Skyjack’s color coded and numbered wiring system, make our machines the easiest to trouble shoot and repair which means easier maintenance and lowered costs.
Our Used equipment will receive an annual inspection and receive at a minimum four 6-volt good tested batteries, a tested charger, good tires, and new decals.
All of our lifts are serviced.
We can replace any component with a new version and touch up any paint if requested!
Work Height 32’ (9.75 m)
Raised Platform Height 26’ (7.92 m)
Lowered Platform Height 45” (1.14 m)
Overall Width 46” (1.17 m)
Overall Length 91” (2.31 m)
Stowed Height (Rails Up) 84.5” (2.15 m)
Stowed Height (Rails Down) 70.5” (1.79 m)
Platform Width (Inside Dimension) 42” (1.07 m)
Platform Length (Inside Dimension) 84” (2.13 m)
Extension Deck (Roll Out) 4’ (1.22 m)
Ground Clearance (Stowed) 3.5” (8.89 cm)
Ground Clearance (Raised) 0.75” (1.91 cm)
Wheelbase 69” (1.75 m)
Weight 4,700 lbs (2,132 kg)
Gradeability 30%
Capacity (Overall) 1,000 lbs (454 kg)
Distributed Capacity (Main Platform) 700 lbs
Wind Rating 28 mph
Tire Size 16 x 5 x 12
